"The SMART stone CLADDING SYSTEM, SIMPLICITY, SPEED & STRENGTH.

Whichever way YOU look at it the RESULTS are TRULY OUTSTANDING."



Forget messy wet fix mortar, forget curing time, forget consuming precious time, forget costly specialist trades, the new SmartClip cavity installation system is the perfect dry hang solution. Direct to stud installation eliminates the need for extra expensive substrates to adhere the claddings to.  It’s a very clean system that is unaffected by stops/slowdowns in wet and freezing climates.

FOR THERMAL INSULATION PERFORMANCE DETAILS SEE HERE



The SmartClip was specifically designed for use with the EcoSmart Stone and TechStone insulated lightweight claddings. It is the affordable solution to enjoying the beauty of stone without the high cost. It's fast and simple. The ease of the SmartClip system makes it perfect for the competent DIY builder or renovator.

HERES HOW  IT WORKS?

All EcoSmart Stone, FibreCLAD and TechStone cladding panels are factory grooved to accommodate the  vertical and horizontal alignment joiners. These slot into each SmartClip and each stone panel ensuring all stone is perfectly aligned without continual leveling checks.



As long as the wall studs are all level then all facing will remain aligned. These should be checked for level before installation commences. In the event the studs are not level then you will need to pack out the SmartClip brackets accordingly.



Care must be taken to ensure the full length bottom rail is level and true as this is the decider for the true alignment of the complete finished job.



All grooves and alignment joiners should have the adhesive applied before the placement of the each stone panel to ensure a completely waterproof cladding facade.



Insulated fireproof backing



Fireproof facades - sandstone cladding, limestone veneer, cladding stone, slate, stone façade, stone walling, cultured stone, wall  stone, lightweight veneer stone, lightweight cladding stone, curtain wall, insulated thermal cladding,sandstone,limestone,veneer,cladding,quartz

SmartClip Bracket

Aluminium

PVC Bracket.jpg

SmartClip Bracket

PVC

Fireproof sandstone facades, limestone veneer, cladding stone, slate, stone façade, stone walling, cultured stone, wall  stone, lightweight veneer stone, lightweight cladding stone, curtain wall, insulated thermal cladding,sandstone,limestone,veneer,cladding,quartz

Multi-Rail   Starter / Sill / Lintel / Reveal

Timber or Metal frame

Stud frame

System Thermal

  Value R-3.0



Breather Foil fixed here



Insulated stone wall and veneer cladding system - ventilated facade systems

18mm  Cavity

           I

Alignment Joiner

Natural Stone Facing

Alignment Groove ----

Breather foil  membrane

SmartClip bracket

Patent Pending SmartClip



The above stone cladding provides a system thermal value of R-3.0

See below for click through sequencial installation process for timber/metal framing construction.

To play, press and hold the enter key. To stop, release the enter key.

Below shows typical window and door return detail (Basalt Bluestone) on a timber/metal stud framed construction.

Basalt stone wall cladding - EcoSmart Stone window return setback detail
